T-Power

7kW Bidirectional V2G Charger
$8,999.00 $8,999.00
In stock: 5
Description

The future of energy management is here. The 7kW Bidirectional V2G Charger from T-Power does more than just charge your electric vehicle—it turns your EV into a powerful energy hub for your home or business.

Unlike standard chargers, the 7kW Bidirectional V2G Charger allows you to both charge your car and discharge power back to your home (V2H) or the grid (V2G). Use your EV battery to power appliances during peak tariff times, provide backup power during an outage, or export stored energy to the grid where approved by your network operator and energy retailer

Why Choose the 7kW Bidirectional V2G Charger for Your Home or Fleet?

  • One Charger, Two Jobs: With true 7kW DC bidirectional power, the 7kW Bidirectional V2G Charger charges your EV and then discharges up to 7kVA AC to power your home or office.

  • Engineered for Australian Conditions: Built to perform in extreme weather, with an IP65 rating for dust and water resistance and an operating temperature range from -25°C to 50°C.

  • Future-Proof Communication: Connectivity & Standards: IEC 62196 (CCS2) charging interface, RS485/CAN, and Bluetooth/Wi-Fi standard, with optional 4G and Ethernet modules

  • Smart & Easy to Use: Control and monitor the charger via the intuitive 5-inch touchscreen or remotely using Wi-Fi, 4G, or Ethernet.

  • Safe & Reliable: Features transformer isolation, an emergency stop button, and voltage monitoring with overvoltage and undervoltage protection for added safety.

Share

Model : TBC7K1000-AY1-CCS2 / TBC7K1000-AY1-CCS2-G2
Product Type: 7kW DC Bidirectional V2G Charger
Charging / Discharging Power: 7kW DC / 7kVA AC
Energy Flow: Bidirectional (Charge & Discharge)
DC Voltage Range: 200VDC ~ 1000VDC (Rectifier) / 300VDC ~ 1000VDC (Inverter)
AC Voltage : 230VAC
Display: 5-inch Touchscreen
Communication Protocol: OCPP 1.6J
Connectivity Options: BLE / Ethernet / Wi-Fi / 4G / RS232 / RS485 / CAN
User Access: QR-code / RFID / BLE / Plug & Charge
Protection Rating: IP65
Operating Noise: ≤55dB
Standby Power Consumption: <15W
Operating temperature range: -25°C to +50°C
Safety Features: Transformer Isolation, Emergency Stop, Voltage Monitoring
Applications: Public Parking, Fleet Depots, Homes, Energy Storage Systems
Installation Options: Wall-mounted / Floor-standing
Charging Standard : IEC 62196(CCS2)
